Descriere
Caracteristicile managementului |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| Switch type | Managed |
| Switch layer | L2+ |
| MIB support | RFC1213, RFC2233, RFC1643, RFC1493, RFC2674, RFC2819, RFC2021, RFC2620, RFC2618, RFC2925 |
| ARP inspection | Yes |
| System event log | Yes |
| Configuring Location Settings (CLI) | Yes |
| Cloud-managed | Yes |
Conexiune |
| SFP+ module slots quantity | 4 |
| Console port | RJ-45/Micro-USB |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| 2.5G Ethernet (copper) ports quantity | 24 |
Reţea |
| Flow control support | Yes |
| Ethernet LAN data rates | 10,100,1000,2500,10000 Mbit/s |
| Networking standards | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3ae,IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt,IEEE 802.3bz,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| VLAN support | Yes |
| Link aggregation | Yes |
| Full duplex | Yes |
| Virtual LAN features | MAC address-based VLAN,Port-based VLAN,Protocol-based VLAN,Stacked VLAN,Tagged VLAN,Voice VLAN |
| 10G support | Yes |
| Spanning tree protocol | Yes |
| Broadcast storm control | Yes |
| Rate limiting | Yes |
| Port mirroring | Yes |
| Head-of-line (HOL) blocking | Yes |
| IPv6 routes | 48 |
| IPv4 routes | 48 |
| Half duplex | Yes |
Transmisie de date |
| Jumbo frames support | Yes |
| MAC address table | 32000 entries |
| Switching capacity | 200 Gbit/s |
| Forwarding rate | 148.8 Mpps |
| Static route | Yes |
| Jumbo frames | 9000 |
| Packet buffer memory | 16 MB |
| Number of queues | 8 |
| Number of static routes | 48 |
| Store-and-forward | Yes |
| Number of IP interfaces | 32 |
Securitate |
| Security algorithms | HTTPS,SSH,SSH-2,SSL/TLS |
| Access Control List (ACL) | Yes |
| DHCP features | DHCP client,DHCP relay,DHCP server,DHCP snooping,DHCPv6 client,DHCPv6 snooping |
| IGMP snooping | Yes |
| SSH/SSL support | Yes |
| BPDU filtering/protection | Yes |
| Authentication | Guest VLAN,MAC-based authentication,Port-based authentication |
| Loop protection | Yes |
| Authentication type | AAA,IEEE 802.1x,RADIUS,TACACS+ |
| IP-MAC-Port binding | Yes |
| Static port security | Yes |
| Queue scheduling algorithms | SP,WRR+SP,Weighted Round Robin (WRR) |
| Password protection | Yes |
Specificații (mod transmitere) multicast |
| Multicast support | Yes |
| Multicast Listener Discovery (MLD) snooping | MLD v1/v2 |
Protocoale |
| Management protocols | SNMP v1/v2c/v3 |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| IPv4 & IPv6 features | IPv4/IPv6 access-control list (ACL),IPv6 ping,IPv6 portal,IPv6 tracert |
Design |
| Product colour | Black |
| Rack mounting | Yes |
| LED indicators | Yes |
| Number of fans | 3 fan(s) |
| Form factor | 1U |
| Redundant fans support | Yes |
Performanță |
| Internal memory | 256 MB |
| Flash memory | 32 MB |
| Memory type | DRAM |
Managementul energiei |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 629.1 W |
| Redundant power supply (RPS) support | Yes |
| Power source | AC/PoE |
| Power supply included | Yes |
Curent pe cablu net (PoE) |
| Power over Ethernet plus (PoE+) ports quantity | 16 |
| Power over Ethernet (PoE) | Yes |
| Total Power over Ethernet (PoE) budget | 500 W |
| Power over Ethernet 4PPoE (PoE++) ports quantity | 8 |
Conditii de mediu |
| Heat dissipation | 2153.45 BTU/h |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90 % |
Greutate şi dimensiuni |
| Width | 440 mm |
| Depth | 330 mm |
| Height | 44 mm |
Sustenabilitate |
| Sustainability certificates | CE,Federal Communications Commission (FCC),RoHS |
| Sustainability compliance | Yes |
Datele de ambalare |
| Cables included | AC |
| Quick start guide | Yes |
| Rack mount kit | Yes |
