| Processor |
| Processor cores | 6 |
| Processor cache | 15 MB |
| Processor manufacturer | Intel |
| Bus type | DMI4 |
| Processor codename | Sapphire Rapids |
| Processor cache type | Smart Cache |
| Processor family | Intel Xeon W |
| Box | N |
| Processor socket | FCLGA4677 |
| Processor ARK ID | 233484 |
| Stepping | S3 |
| Processor base frequency | 2.1 GHz |
| Performance cores | 6 |
| Processor base power | 120 W |
| Maximum turbo power | 144 W |
| Processor model | w3-2423 |
| Processor threads | 12 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 4.2 GHz |
| Technical details |
| Vendor | Intel |
| Status | Launched |
| Launch date | Q1''23 |
| Memory speed (max) | 4400 MHz |
| Package carrier | E1B |
| Weight & dimensions |
| Processor package size | 77.5 x 56.5 mm |
| Other features |
| Maximum internal memory | 2000 GB |
| Graphics |
| Discrete graphics card | N |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
| On-board graphics card | N |
| Processor special features |
| Intel® AES New Instructions (Intel® AES-NI) | Y |
| Enhanced Intel SpeedStep Technology | Y |
| Intel Trusted Execution Technology | Y |
| Intel® Active Management Technology (Intel® AMT) | Y |
| Intel VT-x with Extended Page Tables (EPT) | Y |
| Intel 64 | Y |
| Intel® OS Guard | Y |
| Intel Virtualization Technology for Directed I (O (VT-d)) | Y |
| Intel Software Guard Extensions (Intel SGX) | N |
| Intel Virtualization Technology (VT-x) | Y |
| Intel Turbo Boost Max Technology 3.0 | Y |
| Intel® Speed Shift Technology | Y |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel® Boot Guard | Y |
| Intel® Resource Director Technology (Intel® RDT) | N |
| Intel® vPro™ Platform Eligibility | Y |
| Mode-based Execute Control (MBE) | Y |
| Intel® Deep Learning Boost (Intel® DL Boost) | Y |
| Intel® Optane™ DC Persistent Memory Supported | N |
| Intel® Control-flow Enforcement Technology (CET) | Y |
| Intel® Total Memory Encryption | Y |
| Intel® Transactional Synchronization Extensions | Y |
| Intel® Turbo Boost Max Technology 3.0 frequency | 4.2 GHz |
| Intel® Turbo Boost Technology 2.0 frequency | 4 GHz |
| Intel® Platform Firmware Resilience Support | Y |
| Intel vPro® Enterprise Platform Eligibility | Y |
| Intel® Threat Detection Technology (TDT) | N |
| Intel® One-Click Recovery | N |
| Intel® Total Memory Encryption - Multi Key | N |
| Intel® Virtualization Technology with Redirect Protection (VT-rp) | Y |
| Intel® QuickAssist Software Acceleration | N |
| Intel® Remote Platform Erase (RPE) | N |
| Intel® QuickAssist Technology (QAT) | 0 default devices |
| Intel® Dynamic Load Balancer (DLB) | 0 default devices |
| Intel® Data Streaming Accelerator (DSA) | 1 default devices |
| Intel® In-memory Analytics Accelerator (IAA) | 0 default devices |
| Intel® Advanced Matrix Extensions (AMX) | Y |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Y |
| Intel® Turbo Boost Technology | 2.0 |
| Features |
| Execute Disable Bit | Y |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Embedded options available | N |
| Maximum number of PCI Express lanes | 64 |
| Market segment | Workstation |
| Supported instruction sets | SSE4.1, AMX, SSE4.2, AVX 2.0, AVX-512 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G180729 |
| Use conditions | Workstation |
| Direct Media Interface (DMI) Revision | 4.0 |
| PCI Express slots version | 5.0 |
| Logistics data |
| Harmonized System (HS) code | 8542310001 |
| Operational conditions |
| Tcase | 62 °C |
| DTS Max | 74 °C |
| Memory |
| ECC | Y |
| Maximum internal memory supported by processor | 2000 GB |
| Memory types supported by processor | DDR5-SDRAM |
| Memory channels | Quad-channel |
